#include "TrafPars3dAffine.hpp"
Inheritance diagram for TrafPars3dAffine:
Public Types | |
| typedef Array< double, 3 > | ArrayD3 |
| point coordinate array | |
| typedef Array< double, 12 > | ArrayD12 |
| transformation parameters array | |
| typedef Array< double, 144 > | ArrayD144 |
| QXX matrix array. | |
Public Member Functions | |
procMode | |
processing mode (local, continuous, global)
| |
| void | setProcMode (const LSMProcMode::Type &mode) |
| const LSMProcMode::Type & | getProcMode () const |
IdGridMov | |
}@ (alpha-numerical) grid ID of movable dataset | |
| void | setIdGridMov (const String &id) |
| const String & | getIdGridMov () const |
IdGridFix | |
}@ (alpha-numerical) grid ID of fixed dataset | |
| void | setIdGridFix (const String &id) |
| const String & | getIdGridFix () const |
RefPointMov | |
}@ coordinates of reference point of movable dataset | |
| void | setRefPointMov (const ArrayD3 &refPt) |
| const ArrayD3 & | getRefPointMov () const |
RefPointFix | |
}@ coordinates of (optional) reference point of fixed dataset | |
| void | setRefPointFix (const ArrayD3 &refPt) |
| const ArrayD3 & | getRefPointFix () const |
TrafPars | |
}@ transformation parameters arrray | |
| void | setTrafPars (const ArrayD12 &trfPars) |
| const ArrayD12 & | getTrafPars () const |
Qxx | |
}@
| |
| void | setQxx (const ArrayD144 &myQxx) |
| const ArrayD144 & | getQxx () const |
sigma_0 | |
}@
| |
| void | setSigma0 (const double &sig0) |
| const double & | getSigma0 () const |
nrObs | |
}@ number of observations used for traf pars estimation | |
| void | setNrObs (const unsigned &nob) |
| const unsigned & | getNrObs () const |
of traf pars estimation relativeTrafo | |
|
whether the parameter denotes a relative transformation between two strips | |
| bool | relativeTrafo () const |
| static bool | exportsPythonType () |
| }@ | |
| static const char * | help () |
| static const char * | syntax () |
Additional Inherited Members | |
| Static Public Member Functions inherited from CustomOptionType< TrafPars3dAffine > | |
| static const char * | _help () |
| get general help on this type | |
| static const char * | _syntax () |
| get the syntax used for parsing this type | |
| static bool | _exportsPythonType () |
| returns true if this type is exposed to Python as a custom type, false otherwise (if it is represented as Python-string) | |
| Protected Member Functions inherited from CustomOptionType< TrafPars3dAffine > | |
| ~CustomOptionType () | |
| protected, must be derived from | |
Detailed Description
This class contains the transformation parameters of an affine 3D (i.e. 12-parameter) transformation, given as 12-array trafPars (
), representing the affine transformation matrix A and the translation vector t
![\[ A = \begin{pmatrix} tp_1 & tp_2 & tp_3 \\ tp_5 & tp_6 & tp_7 \\ tp_9 & tp_{10} & tp_{11} \end{pmatrix} \]](form_49.png)
![\[ t = \begin{pmatrix} tp_4 \\ tp_8 \\ tp_{12} \end{pmatrix} \]](form_50.png)
The transformation is defined as follows:
![\[ y = A(x-x_0) + t + x_0 \]](form_51.png)
with
![\[ \begin{matrix} y & \ldots & \text{point in destination ("fix") system} \\ x & \ldots & \text{point in source ("mov") system} \\ x_0 & \ldots & \text{source system's reference point (reduction point; refPointMov)} \\ \end{matrix} \]](form_52.png)
The 144-array
contains the
matrix of trafPars:
![\[ Q_{xx} = \begin{pmatrix} q_{1 }(a_{1,1},a_{1,1}) & q_{2 }(a_{1,1},a_{1,2}) & q_{3 }(a_{1,1},a_{1,3}) & q_{4 }(a_{1,1},t_1) & q_{5 }(a_{1,1},a_{2,1}) & \ldots & q_{12 }(a_{1,1},t_3) \\ q_{13 }(a_{1,2},a_{1,1}) & q_{14 }(a_{1,2},a_{1,2}) & q_{15 }(a_{1,2},a_{1,3}) & q_{16 }(a_{1,2},t_1) & q_{17 }(a_{1,2},a_{2,1}) & \ldots & q_{24 }(a_{1,2},t_3) \\ q_{25 }(a_{1,3},a_{1,1}) & q_{26 }(a_{1,3},a_{1,2}) & q_{27 }(a_{1,3},a_{1,3}) & q_{28 }(a_{1,3},t_1) & q_{29 }(a_{1,3},a_{2,1}) & \ldots & q_{36 }(a_{1,3},t_3) \\ q_{37 }(t_{1 },a_{1,1}) & q_{38 }(t_{1 },a_{1,2}) & q_{39 }(t_{1 },a_{1,3}) & q_{40 }(t_{1 },t_1) & q_{41 }(t_{1 },a_{2,1}) & \ldots & q_{48 }(t_{1 },t_3) \\ q_{49 }(a_{2,1},a_{1,1}) & q_{50 }(a_{2,1},a_{1,2}) & q_{51 }(a_{2,1},a_{1,3}) & q_{52 }(a_{2,1},t_1) & q_{53 }(a_{2,1},a_{2,1}) & \ldots & q_{60 }(a_{2,1},t_3) \\ \vdots & \vdots & \vdots & \vdots & \vdots & \ddots & \vdots \\ q_{133}(t_{3 },a_{1,1}) & q_{134}(t_{3 },a_{1,2}) & q_{135}(t_{3 },a_{1,3}) & q_{136}(t_{3 },t_1) & q_{137}(t_{3 },a_{2,1}) & \ldots & q_{144}(t_{3 },t_3) \\ \end{pmatrix} \]](form_55.png)
- Date
- 10.11.2009
Describes a relative or absolute 3D-affine transformation.
Member Function Documentation
|
inline |
TrafPars3dAffine can either be used to specify the best fitting transformation between to overlapping ALS strips or in a global sense (after strip adjustment) The (optional) members s_idGridFix/refPointFix are used to communicate information about the strip used for the traf pars estimation. No such info is provided in case of global transformation parameters.
